What is a Rocket Stove?

By Vuthisa

Dr. Larry Winiarski, now Technical Director of Aprovecho, began developing the Rocket stove in 1980 and invented the principles of the Rocket stove in 1982. The Winiarski Rocket stove’s simple design and use of common materials make it easily modified for optimal performance. In the last 29 years, variations of the Rocket stove have been built in over 20 countries. The Rocket elbow can be made from different materials such as sand/clay (Lorena), pumice/concrete, heavy steel pipe, 430 stainless steel or refractory ceramic. Find a comprehensive list of Websites, Videos, Downloads and Manufacturers at the bottom of this page with regards to building, using or purchasing a Rocket stove. Click here to go to References

What’s wrong with an open fire?

An open fire, as shown above, is often 90% efficient in turning wood into energy. But only a small proportion (10% to 40%), of the released energy makes it into the pot. Improving combustion efficiency does not appreciably help the stove to use less fuel. On the other hand, improving heat transfer efficiency to the pot makes a large difference. Improving the combustion efficiency is necessary to reduce smoke and harmful emissions that damage health. Improving heat transfer efficiency can significantly reduce fuel use. Fire is naturally good at its job, but pots are not as good at capturing heat because they are inefficient heat exchangers. In order to reduce emissions and fuel use, the stove designer’s job is to first clean up the fire and then force as much energy into the pot or griddle as possible. Both of these functions can be accomplished in a well engineered cooking stove and a Rocket stove. A Rocket stove is a type of stove combining the air-intake with the fuel-feed slot in an opening into the combustion chamber extending into an “internal chimney” before exiting through the vertical chambered heat exchanger.  Some models have the chimney located in a different location, drawing emission gases along a horizontal path (sometimes below cooking points) before exiting through the vertical chimney.

Click on image above to play GIF animation

Or download image here.

A Rocket stove is signified by ease of construction and simplicity of building materials while accepting small-diameter fuel such as twigs or small branches, yielding high combustion efficiency and directing the resultant heat most effectively. A Rocket stove achieves efficient combustion of the fuel at a high temperature by ensuring that there is a good air draft into the fire, controlled use of fuel, complete combustion of volatiles, and efficient use of the resultant heat.  As the fuel burns within the combustion chamber, convection draws in new air from below ensuring that any smoke from smoldering wood near to the fire is also drawn into the fire and up the chimney. The chimney should be insulated to maximize the temperature and improve combustion.  The design of the stove means that it can operate on about half as much fuel as a traditional open fire and can use smaller diameter wood. Some models can accept whole logs, with only the tips combusting. In horizontal feed magazines the fuel has to be pushed into the combustion chamber at regular intervals. The advantage of this system is that the heat output can be adjusted as required, but the disadvantage is that if left unattended the fire will extinguish.

Rocket stoves are usually insulated and some are raised up from the floor which reduces the danger of children burning themselves. For space heating purposes the heat is transferred to a heat store which can in some cases be part of the structure of the house itself. The exhaust gases then pass out of the building via the chimney. The use of a cooking hood is recommended as the hood and chimney combination does not influence the rate at which air is introduced to the fire. The “internal chimney” creates the optimum amount of draft for fuel-efficient combustion.

A Rocket stove’s main components are:

Fuel magazine: Into which the unburned fuel is placed and from where it feeds into the combustion chamber. The fuel magazine can be horizontal where additional fuel will be added manually or vertically for automatic feeding (gravity feed) of fuel. The fuel magazine can be simple steel piping or even ceramic pipe. Fuel shelves serve as the platform for the fuel that is used with the stove. This slightly raised platform makes it possible for air to flow over and under the fuel source.

Combustion chamber/Internal chimney: At the end of the fuel magazine where the wood is burned. Internal chimneys are mere extensions of the combustion chamber and may be constructed from a larger tin can to piping and provide the required draft to maintain the fire. The top of the combustion chamber/chimney serve as the support for the cooking area. Some Rocket stove designs have chimneys in a separate location to the combustion chamber.

Chimneys: Located above the combustion chamber or to one side or can be part of the hood extraction system.

Heat exchanger: To transfer the heat to where it is needed, i.e. the cooking pot. From the chimney the heat passes into a suitable heat exchanger to ensure the efficient use of the generated heat. For cooking purposes the design keeps the cooking vessel in contact with the fire over the largest possible surface area by use of a pot skirt to create a narrow channel which forces hot air and gas to flow along the bottom and sides of the cooking vessel. The pot is usually encompassed by a fixed or adjustable pot skirt. The pot skirt functions as a shield to force the emission gases to pass close to the container holding the food. The gap between the skirt and the pot is also known as the pot gap. The pot gap calculation is crucial to the performance of the stove and excel spreadsheets are usually used to calculate this gap.

Rocket stoves are found more commonly in third world countries where wood fuel sources are scarce but it has been introduced in the United States in recent years. Some of them are small for portability with insulation inside a double-walled design with a chamber for partial biomass gasification and additional mixing to increase power output and provide a cleaner, more complete burn. In some models, as the wood is converted to charcoal, it falls through a grate for later collection and carbon sequestration. Since the Rocket stove is a wood burning cooking stove, obtaining fuel while on a camping trip is easy. Unlike a campfire, the Rocket stove will function very well using small branches and limbs that tend to litter the floor of the woods. This means there is no need to chop larger sections of wood into smaller sections in order to feed the fire.


http://en.wikipedia.org/wiki/Rocket_stove Definition of a Rocket stove
http://www.bioenergylists.org/stovesdoc/Still/Rocket%20Stove/Principles.html Larry Winiarski’s Rocket Stove Principles (Dean Still)
http://www.bioenergylists.org/stovesdoc/Design/Design.html Biomass Cookstove Design and Testing
http://www.ehow.com/how_2265305_build-winiarski-rocket-stove.html#ixzz1H5MC0jJa How to Build a Winiarski Rocket Stove
http://www.ehow.com/how_4507160_build-rocket-stove.html How to Build a Rocket Stove
http://www.ehow.com/how_6550436_make-rocket-stove-camping.html How to Build a Rocket Stove for Camping
http://www.rocketstove.org Where you go on the web to find (or to learn how to make) Rocket stoves that work (Peter Scott)
http://www.treehugger.com/files/2009/03/rocket-stoves.php Rocket Stoves: Build Your Own Ultra-Efficient Cook Stove (Video)
http://www.mnn.com/your-home/at-home/stories/rocket-stoves-tips-for-designing-your-own Rocket stoves: Tips for designing your own
http://www.rocketstoves.com/ Website of the Book Rocket Mass Heaters
http://www.pyroenergen.com/articles08/eco-rocket-stove.htm PYRO-Eco Stove for Cooking on Rural Areas (Junji Takano)
http://bioenergylists.org/en/taxonomy/term/ Rocket stoves (9 web pages)
http://www.appropedia.org/CCAT_rocket_stove Campus Center for Appropriate Technology (CAT) Rocket stove
http://www.squidoo.com/rocketstoves Rocket Stoves – Cool Name, Hot Stove
http://www.rootsimple.com/2007/11/our-rocket-stove.html Our Rocket Stove
http://solarcooking.wikia.com/wiki/Rocket_Stove Rocket stove
http://www.wonderhowto.com/how-to-build-and-understand-rocket-stove-331886/ How to build and understand a Rocket stove
http://mdulastove.wordpress.com/ Holey Roket (as in Rok+et) : a biomass briquette stove type by Rok Oblak
http://www.stoveteam.org/ Home to the Ecocina Rocket stove
http://vuthisa.com/news/rocket-stove/ Examples of Rocket stove installations in South Africa
http://www.meadowforge.co.uk/DK_rocket_stoves.htm The DK Rocket stove (UK)

http://www.youtube.com/watch?v=XSMR2ANIZ7E How to Make a 16 Brick Rocket Stove
http://www.youtube.com/watch?v=235m0EzZF4U DRTV Rocket Stoves
http://www.youtube.com/watch?v=LfKHVoCY2so 12 Rocket stove mass heaters – efficient wood heat
http://www.aprovecho.org/web-content/media/rocket/rocket.htm How to build a Rocket Stove
http://video.google.com/videoplay?docid=797446823830833401# How to make a Rocket stove by Vavrek
http://www.youtube.com/watch?gl=IE&hl=en-GB&v=eqUsUMlyIeQ Coffee can Rocket stove by Rich
http://www.youtube.com/watch?v=gO-vPyCShLg&feature=player_embedded#at=94 How to Make a Tin Can Rocket Stove by Larry Winiarski
http://www.rocketstove.org/index.php?option=com_content&task=view&id=42&Itemid=93 How to build an institutional Rocket stove – Part 1 to 8 by Peter Scott
http://www.youtube.com/watch?v=YIMi0DVDvqw&feature=player_embedded Build a Rocket stove by Aprovecho
http://www.youtube.com/watch?v=CsDjcv5vO4c&feature=related Operation of the StoveTec Combo Two Door Stove by Dean Still
http://www.richsoil.com/rocket-stove-mass-heater.jsp Rocket stove mass heater – website containing various instructional videos
http://www.youtube.com/watch?v=GmEiLMT56L0&feature=player_embedded Redneck Rocket Stove using cinder blocks
http://www.youtube.com/watch?v=vJ7WjwAqeX0 How to assemble special bricks into a Six Brick Rocket Stove with Ken Goyer by Aid Africa
http://www.youtube.com/watch?v=9uh2VExcdbY&feature=player_embedded#at=221 The principles of a Rocket stove and how to build one – Institutional type
http://mdulastove.wordpress.com/holey-rocket/holey-roket-making/ Holey Roket Making (as in Rok+et) by Rok Oblak
http://www.youtube.com/watch?v=2fmp23SdS2Y Ecocina step by step
http://youtu.be/9CM4K5K-TiI Happy Rocket stove users in South Africa
http://wn.com/Rocket_Stove_Workshop World News now hosts many YouTube videos on Rocket stoves

http://stoves.bioenergylists.org/stovesdoc/apro/Institutional_Rocket.pdf The Institutional Rocket Stove Designed by Dr. Larry Winiarski
http://www.bioenergylists.org/stovesdoc/Pcia/Design%20Principles%20for%20Wood%20Burning%20Cookstoves.pdf Design Principles for Wood Burning Cook Stoves
http://stoves.bioenergylists.org/stovesdoc/Still/AprovechoPlans/Rocket%20Stove%20Design%20Guide.pdf Rocket stove design guide
http://www.bioenergylists.org/stovesdoc/Scott/malawi/Malawi%20Repor1.pdf (See page 9 for fire brick recipes) Introduction of Rocket Stove Technologies (Institutional stoves, Household stoves and insulative refractory bricks) Into Malawi, March- July 2004
http://stoves.bioenergylists.org/stovesdoc/Scott/malawi/Malawi_ReportAug05.pdf Malawi Report
Feb 1st – April 11th, 2005
http://stoves.bioenergylists.org/stovesdoc/apro/guide/HOUSEHOLD%20Stoves%20Construction%20Manual%20Nov%202004.pdf MINISTRY OF ENERGY AND MINERAL DEVELOPMENT Energy Advisory Project HOW TO BUILD THE IMPROVED HOUSEHOLD STOVES
http://www.rocketstove.org/images/stories/chimney%20tool/IRS%20Assembly%20Guide%2010%2027%202010%20new.pdf Institutional Rocket Stove (IRS) Assembly Guide Designed by Peter Scott
http://www.rocketstove.org/images/stories/chimney%20tool/IRS%20Calculation%20Sheet%2010%2026%202010.xls Pot gap calculation


https://rocketworks/org – Rocket Works
http://www.stovetec.net/us/index.php – StoveTec
http://www.envirofit.org/cookstoves.html – Envirofit

http://www.stockstorage.com/The Grover Rocket Stove
http://www.meadowforge.co.uk/DK_rocket_stoves.htmThe DK Rocket Stove
